P80 Hydraulic Valve: Factory Direct Supply & Global Distribution

Metoda sterowania:Elektromagnes

Szpula:5-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:200 bar (2900 psi)

Port wlotowy:G1/2

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:33*44*11

Waga brutto:19.50 kg

Dostępność: W magazynie

1172 Osoby oglądają ten produkt

P80 Hydraulic Valve: Factory Direct Supply & Global Distribution

P80 Hydraulic Valve: Factory Direct Supply & Global Distribution

P80 Hydraulic Valve: Factory Direct Supply & Global Distribution drawing image

The P80 Series Spool Directional Control Valve is a high-performance hydraulic valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. This 5-section monoblock valve features a solenoid control method, a rated flow of 80 L/min, and a maximum pressure of 250 bar. Available for factory direct supply and global distribution.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Spool Directional Control Valve is a robust and reliable hydraulic valve manufactured to the highest standards. This 5-section monoblock valve features a solenoid control method for precise operation. With a rated flow of 80 L/min and a maximum pressure of 250 bar, the P80 valve is suitable for a wide range of applications, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. We offer factory direct supply and global distribution, allowing you to access high-quality hydraulic valves at competitive prices. Contact us to discuss your specific requirements and explore our range of manufacturing, OEM, private label, and customized solutions.
