Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:120 l/min (31.7 US gpm)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1

Port wylotowy:G1

Rozmiar portu:G1

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P120 Zawór sterujący jednoczęściowy

Rozmiar opakowania:30*39*17

Waga brutto:19.00 kg

Dostępność: W magazynie

1489 Osoby oglądają ten produkt

Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM

Manual Monoblock Directional Valve - P120 Series | Wholesale & OEM drawing image

The P120 Series 12v Electric Hydraulic Valve is a manual monoblock directional valve designed for a wide range of applications, including construction, agriculture, and material handling. This 2-section valve features a rated flow of 120 L/min and a maximum pressure of 250 bar, making it ideal for use in telehandlers, forklifts, excavators, and other heavy-duty equipment.

Seria P120 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny
Przepływ znamionowy 120 l/min (31.7 US gpm)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port wylotowy G1, SAE 16, 1 NPT, M36×2
Rozmiar portu G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje
Typ konstrukcji Zawór blokowy
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)

This 12v Electric Hydraulic Valve from the P120 series is a reliable and durable solution for your hydraulic system needs. With a manual control method, 2 sections, and a monoblock structure, this valve offers precise control over hydraulic fluid flow. Featuring a rated flow of 120 L/min and a maximum pressure of 250 bar, the valve is well-suited for a variety of applications, including material handling, construction, and agriculture. Its robust design ensures long-term performance even in demanding environments. Available for wholesale and OEM orders, this valve can be customized to meet your specific requirements. Its versatility makes it an ideal choice for various heavy-duty equipment, such as telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
