Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Metoda sterowania:Ręczna

Szpula:1-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:23*16*11

Waga brutto:3.00 kg

Dostępność: W magazynie

1021 Osoby oglądają ten produkt

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT drawing image

Introducing Your Hydraulic Partner: a leading provider of OEM, ODM, and White Label services for hydraulic products. Our expertise lies in developing and manufacturing high-quality hydraulic components and systems tailored to meet your specific needs. Partner with us to elevate your product offerings with our exceptional manufacturing capabilities and commitment to innovation.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40-G12-1OT monoblock valve is a prime example of our engineering prowess. Designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles, this valve delivers exceptional performance with a rated flow of 40 L/min, a maximum pressure of 250 bar, and an operating viscosity range of 15 - 75 mm²/s. Its robust construction ensures reliable operation in harsh environments with an ambient temperature range of -40°C to +80°C. Whether you require OEM manufacturing, ODM customization, or White Label branding, we have the expertise and infrastructure to fulfill your requirements. Our commitment to quality and customer satisfaction sets us apart, making us the ideal choice for businesses seeking a reliable hydraulic partner.
