Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:SAE 8

Port wylotowy:SAE 8

Rozmiar portu:SAE 8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:23*18*13

Waga brutto:4.80 kg

Dostępność: W magazynie

977 Osoby oglądają ten produkt

Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct

Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct

Wholesale Hydraulic Valves: P40-U34-2OT Series | Factory Direct drawing image

Our P40-U34-2OT Series solenoid valve is a high-quality, durable, and reliable hydraulic valve designed for a wide range of applications in construction, material handling, agriculture, and industrial vehicles. We offer factory direct wholesale pricing for bulk orders.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This 2-section monoblock valve features a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure rating of 250 bar (3600 psi). It is designed for use with hydraulic fluids with a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can operate in ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve is available for various applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. As a manufacturer, we offer a variety of options including OEM, private labeling, customization, and wholesale pricing. We are also actively seeking distributors, wholesalers, agents, and traders to expand our global reach. Contact us today for more information and a competitive quote.
