White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve

Metoda sterowania:Pneumatyczna

Szpula:2-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:23*18*13

Waga brutto:6.00 kg

Dostępność: W magazynie

1077 Osoby oglądają ten produkt

White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve

White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve

White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve drawing image

Introducing our premium White Label Solutions for P40 Pneumatic 2 Spool Monoblock Directional Valve, meticulously engineered to meet the diverse needs of global markets. This exceptional valve boasts a rated flow of 40 L/min (10.5 US gpm) and withstands pressure up to 250 bar (3600 psi), making it ideal for demanding applications in various industries.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40 Series Pneumatic Directional Valve stands out with its exceptional performance and versatility. With its 2 spool design and monoblock structure, this valve ensures precise control and durability. Operating seamlessly within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F), it adapts effortlessly to challenging environments. This valve finds its application in diverse industries, including material handling, construction and earth moving, agriculture, and industrial vehicles, making it an indispensable component for a wide range of machinery. As a leading manufacturer, we offer unparalleled OEM, private label, and custom solutions to cater to your specific requirements. Our commitment to quality and customer satisfaction drives us to provide tailored products that meet your unique demands.
