Produkcja i dostawa
Czas realizacji produkcji 15-30 dni



The P80-G34-5OT 5 Spool Directional Valve is a heavy-duty, high-performance hydraulic valve designed for use in a wide range of construction, agricultural, and industrial applications. This 5-section monoblock valve features manual control, 80 L/min flow rate, and 250 bar maximum pressure, making it ideal for demanding tasks.
| Seria P80 Zawór sterujący jednoczęściowy Parametry | |
|---|---|
| Metoda sterowania | Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick |
| Szpula | 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny |
| Zakres temperatury otoczenia | -40°C do +80°C (-40°F do +176°F) |
| Typ konstrukcji | Zawór blokowy |
| Sekcja | 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji |
| Zakres lepkości roboczej | 15 - 75 mm²/s (15 cSt do 75 cSt) |
| Przepływ znamionowy | 80 l/min (21,2 USGPM) |
| Maksymalne ciśnienie | 315 bar (4600 psi) |
| Port wlotowy | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port wylotowy | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Rozmiar portu | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
This P80 series auxiliary hydraulic valve is a top-of-the-line product manufactured for global markets. It is a 5-spool directional valve with manual control, designed for use in a variety of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. The valve is a monoblock structure with a rated flow of 80 L/min and a maximum pressure of 250 bar. It is suitable for a wide range of operating viscosity, from 15 to 75 mm²/s, and can withstand ambient temperatures from -40°C to +80°C. The valve is designed for use in a variety of applications, including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, face drill rigs, concrete boom pumps, pave rollers, rotary drilling, crushers, and stone cutters. This high-quality valve offers durability, reliability, and high performance, making it an excellent choice for demanding applications.
