Solenoid Directional Control Valve - P80 Series | Wholesale & OEM

Metoda sterowania:Elektromagnes

Szpula:1-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:200 bar (2900 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:37*12*11

Waga brutto:4.80 kg

Dostępność: W magazynie

1564 Osoby oglądają ten produkt

Solenoid Directional Control Valve - P80 Series | Wholesale & OEM

Solenoid Directional Control Valve - P80 Series | Wholesale & OEM

Solenoid Directional Control Valve - P80 Series | Wholesale & OEM drawing image

The P80 Series Hydraulic Valve Bank is a high-performance, 2-section solenoid directional control valve designed for a variety of applications in material handling, construction, agriculture, and industrial vehicles. Featuring a compact monoblock design, it offers a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi). This versatile valve is perfect for OEM and wholesale customers looking for reliable and durable hydraulic components.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Hydraulic Valve Bank is a 2-section solenoid directional control valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. Its compact monoblock design ensures space-saving installation, while the solenoid control provides precise and responsive actuation. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve is capable of handling high-flow, high-pressure hydraulic systems. The valve's robust construction and wide operating temperature range (-40°C to +80°C) guarantee reliable performance in various environments. This versatile valve is ideal for OEM and wholesale customers seeking a high-quality, durable, and reliable hydraulic component for their applications.
