SD8 2 Spool Pneumatic Hydraulic Sectional Valve with High Pressure

Metoda sterowania:Pneumatyczna

Szpula:2-sekcyjny

Przepływ znamionowy:90 l/min (23,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:SAE 10

Port wylotowy:SAE 10

Rozmiar portu:SAE 10

Marka:BXHS

Typ produktu:Zawór kierunkowy sekcyjny

Seria produktów:Seria SD8 Zawór kierunkowy sekcyjny

Rozmiar opakowania:34*24*15.5

Waga brutto:12.50 kg

Dostępność: W magazynie

106 Osoby oglądają ten produkt

SD8 2 Spool Pneumatic Hydraulic Sectional Valve with High Pressure

SD8 2 Spool Pneumatic Hydraulic Sectional Valve with High Pressure

SD8 2 Spool Pneumatic Hydraulic Sectional Valve with High Pressure drawing image

The SD8 2 Spool Pneumatic Hydraulic Sectional Valve is a high-performance control solution designed for flow rates up to 80 L/min and pressures up to 350 bar. Featuring pneumatic actuation, this versatile valve is engineered for demanding applications in agriculture, material handling, and construction machinery.

Seria SD8 Zawór kierunkowy sekcyjny Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny, 8-sekcyjny, 9-sekcyjny, 10-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji, 8 Sekcji, 9 Sekcji, 10 Sekcji
Zakres lepkości roboczej 12 - 400 mm²/s (12 cSt do 400 cSt)
Przepływ znamionowy 90 l/min (23,8 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, SAE 10
Port wylotowy G1/2, G3/4, SAE 10, 3/4 NPT
Rozmiar portu G1/2, SAE 10

As a leading manufacturer of premium hydraulic components, we present the SD8 Series 2 Spool Pneumatic Hydraulic Sectional Valve. Engineered for heavy-duty performance, this valve supports a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 350 bar (5100 psi), making it suitable for forklifts, mini-excavators, and harvesters. We specialize in global supply, offering extensive opportunities for OEM, ODM, and private labeling to meet specific brand requirements. Our factory provides direct wholesale pricing and custom manufacturing services to ensure superior product integration for industrial vehicles and earth-moving equipment. We are actively seeking long-term cooperation with distributors, wholesalers, regional agents, and international traders to expand our global footprint. By choosing our factory-direct supply, partners benefit from reliable sectional valve technology, G1/2 inlet and G3/4 outlet configurations, and a robust design tailored for wood splitters, sweepers, and waste compactors. Contact us for bulk orders and professional hydraulic manufacturing solutions.
