Reliable P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump Manufacturer Source

Pojemność skokowa:64,6 cm³/obr.

Ciśnienie znamionowe:16 MPa (2320 psi)

Maksymalne ciśnienie:17 MPa (2465 psi)

Maksymalna prędkość:2200 obr./min

Kierunek obrotu:Dwukierunkowy

Marka:BXHS

Typ produktu:Pompa hydrauliczna zębata

Seria produktów:Seria P21 Pompa hydrauliczna zębata

Rozmiar opakowania:45*25*18

Waga brutto:16.00 kg

Dostępność: W magazynie

137 Osoby oglądają ten produkt

Reliable P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump Manufacturer Source

Reliable P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump Manufacturer Source

Reliable P21A646JEAL20-25-H 64.6 cc/rev Hydraulic Gear Pump Manufacturer Source drawing image

This P21 Series Hydraulic Gear Pump features a 64.6 cc/rev displacement, 16 MPa rated pressure, and bidirectional rotation, ideal for forklifts and loaders. Backed by a 25-year Professional Manufacturer with IATF 16949 certification, it ensures reliable performance for construction and agricultural machinery.

Seria P21 Pompa hydrauliczna zębata Parametry
Pojemność skokowa 64,6 cm³/obr.
Ciśnienie znamionowe 16 MPa (2320 psi)
Maksymalne ciśnienie 17 MPa (2465 psi)
Prędkość znamionowa 600 obr./min
Maksymalna prędkość 2400 obr./min
Kierunek obrotu Dwukierunkowy
Materiał Żeliwo
Struktura Zewnętrzna pompa zębata
Wersja kołnierza Flange owalny A, Flange kwadratowy B, Otwory montażowe ISO-4, Otwory montażowe UNI-3, Kołnierz SAE
Typ wału Nacięcie ewolwentowe X

**1. Reliable P21 Series Gear Pump Specifications**
- Engineered with 64.6 cc/rev displacement and bidirectional rotation, operating efficiently at 2000 r/min rated speed.
- Delivers consistent flow up to 2200 r/min max speed, ensuring smooth power transmission for heavy-duty applications.

**2. High-Pressure Hydraulic Gear Pump Performance**
- Rated for 16 MPa (2320 psi) with a max pressure of 17 MPa (2465 psi), providing strong lifting force for material handling.
- Rigorously tested for seal integrity and pressure stability, guaranteeing durability in demanding earth-moving tasks.

**3. Versatile OEM Hydraulic Pump Applications**
- Perfectly compatible with forklifts, telehandlers, skid steer loaders, and backhoe loaders as a direct replacement part.
- Supports diverse industrial vehicles including tractors, sprayers, and waste compactors, offering broad market adaptability.

**4. Factory Direct Sales Quality Assurance**
- Produced by a 25-year Professional Manufacturer with 4 modern factories and an annual capacity of 1,500,000 units.
- Each unit undergoes 100% bench testing for pressure, flow, and leakage, backed by IATF 16949 and CE certifications.

**5. Customizable Wholesale China Factory Solutions**
- Offers full OEM/ODM services including custom logos, casting modifications, and private label packaging for distributors.
- Secured with rust-proof treatment and heavy-duty wooden crate packing, ensuring safe Exported Worldwide delivery.
