P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:SAE 10

Port wylotowy:SAE 12

Rozmiar portu:SAE 10

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*18*11

Waga brutto:8.00 kg

Dostępność: W magazynie

961 Osoby oglądają ten produkt

P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production

P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production

P80-U116-U78-2OT Hydraulic Valve: Private Label & Bespoke Production drawing image

The P80 Series Pressure Reducing Valve is a high-performance hydraulic valve designed for use in a variety of applications, including construction equipment, material handling, agriculture, and industrial vehicles. It features a manual control, monoblock construction, and a rated flow of 80 L/min (21.2 US gpm). The valve is also available with private label and bespoke production options.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-U116-U78-2OT Hydraulic Valve is a pressure reducing valve designed for precise control of hydraulic pressure in a variety of applications. This manual control valve features a compact monoblock construction and a rated flow of 80 L/min (21.2 US gpm). It is designed to withstand a maximum pressure of 250 bar (3600 psi) and operates within a viscosity range of 15-75 mm²/s (15 cSt to 75 cSt). The valve is suitable for a wide range of ambient temperatures, from -40°C to +80°C (-40°F to +176°F). The P80 Series valve is ideal for use in construction equipment, material handling, agriculture, and industrial vehicles. Specifically, it is compatible with telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, and other similar machines. This valve offers private label and bespoke production options, allowing customization to meet specific requirements. This makes it an excellent choice for manufacturers seeking to differentiate their products and provide tailored solutions to their customers.
