P80 Electro-hydraulic 4 Spool Monoblock Valve: OEM & ODM Services Available

Metoda sterowania:Elektrohydrauliczna

Szpula:4-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:50*40*20

Waga brutto:23.00 kg

Dostępność: W magazynie

537 Osoby oglądają ten produkt

P80 Electro-hydraulic 4 Spool Monoblock Valve: OEM & ODM Services Available

P80 Electro-hydraulic 4 Spool Monoblock Valve: OEM & ODM Services Available

P80 Electro-hydraulic 4 Spool Monoblock Valve: OEM & ODM Services Available drawing image

The P80 Electro-hydraulic 4 Spool Monoblock Valve offers high performance and reliability for various applications. It features a rated flow of 80 L/min and a maximum pressure of 315 bar. OEM, ODM, custom design, and wholesale options are available.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Electro-hydraulic 4 Spool Monoblock Valve is a high-performance, robust solution for diverse applications in material handling, construction, agriculture, and industrial vehicles. This 80 L/min valve boasts a maximum pressure of 315 bar and operates efficiently within a wide temperature range (-40°C to +80°C). Its monoblock structure ensures compact design and high reliability. As a leading manufacturer and factory supplier, we provide comprehensive services including OEM, ODM, custom design, and wholesale options. We are seeking distributors, wholesalers, agents, and trading companies to partner with us globally.

**Key Features:**
* Electro-hydraulic control
* 4-spool monoblock design
* Rated flow: 80 L/min (21.2 US gpm)
* Max pressure: 315 bar (4600 psi)
* Wide operating temperature range: -40°C to +80°C (-40°F to +176°F)
* Suitable for forklifts, excavators, tractors, and more.

**Business Opportunities:**
* **OEM:** We can manufacture valves to your specifications, incorporating your branding and requirements.
* **ODM:** We offer design and manufacturing services based on your specific needs.
* **Custom Design:** Our engineering team can create bespoke solutions for your unique applications.
* **Wholesale:** Benefit from our competitive factory direct pricing and bulk order discounts.

We are actively seeking distributors, wholesalers, agents, and trading companies worldwide to expand our global reach. Partner with us and leverage our high-quality products, competitive pricing, and comprehensive services. Contact us today to discuss your partnership opportunities. Factory direct, factory wholesale, and private label options are available.
