P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*18*11

Waga brutto:8.20 kg

Dostępność: W magazynie

1024 Osoby oglądają ten produkt

P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution

P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution

P80-AQF Hydraulic Valve | Customizable Solutions & Global Distribution drawing image

The P80 Series Hydraulic Valve is a 2-section, manual control monoblock valve with a rated flow of 80 L/min and a max pressure of 250 bar. This versatile valve is designed for use in various applications including construction, agriculture, material handling, and industrial vehicles.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Hydraulic Valve is a high-performance, reliable valve designed for demanding applications. It features a robust monoblock construction, 2 sections for precise control, and a manual control method. This valve is suitable for a wide range of equipment, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, tractors, harvesters, bale wrappers, backhoes, seeding machines, sprayers, and balers. It offers a rated flow of 80 L/min and a max pressure of 250 bar, making it ideal for various hydraulic systems. Its operating viscosity range is 15-75 mm²/s, and it can withstand ambient temperatures from -40°C to +80°C. The valve is equipped with a 2-spool configuration, providing flexibility for different control needs. Whether you require a hydraulic valve for construction, agriculture, material handling, or industrial vehicles, the P80 Series offers a robust and reliable solution.
