P40-S Hydraulic Directional Control Valve - Reliable & Durable

Metoda sterowania:Elektromagnes

Szpula:4-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:35*23*15

Waga brutto:12.70 kg

Dostępność: W magazynie

485 Osoby oglądają ten produkt

P40-S Hydraulic Directional Control Valve - Reliable & Durable

P40-S Hydraulic Directional Control Valve - Reliable & Durable

P40-S Hydraulic Directional Control Valve - Reliable & Durable drawing image

The P40-S Hydraulic Directional Control Valve is a reliable and durable 4-section monoblock valve with a 40 L/min rated flow and 250 bar max pressure. Ideal for material handling, construction, agriculture, and industrial vehicles.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

We are a global hydraulic product manufacturer offering manufacturing, OEM, private labeling, customization, and wholesale services. We are seeking distributors, wholesalers, agents, and trading companies. Our flagship product, the **P40-S Hydraulic Directional Control Valve**, is a high-performance, reliable and durable solution for various applications. This **4-section monoblock valve** features solenoid control, a rated flow of 40 L/min (10.5 US gpm), and a maximum pressure of 250 bar (3600 psi). Its **robust construction** and wide operating temperature range (-40°C to +80°C) ensure reliable performance in demanding environments. Key features include:

* **Solenoid Control:** Precise and efficient operation.
* **4-Section Design:** Versatile control for complex hydraulic systems.
* **Monoblock Structure:** Compact design and enhanced durability.
* **High Flow Rate (40 L/min):** Efficient operation for demanding applications.
* **High Pressure Rating (250 bar):** Suitable for heavy-duty equipment.
* **Wide Viscosity and Temperature Range:** Adaptable to various operating conditions.
* **Applications:** Material handling (forklifts, telehandlers), construction and earthmoving (mini-excavators, skid steer loaders), agriculture (tractors, harvesters), and industrial vehicles.

As a **manufacturer and factory supplier**, we offer competitive pricing and flexible solutions to meet your needs. We provide **factory wholesale** options and welcome inquiries for **OEM, private labeling, and custom designs**. We are actively seeking partnerships with **distributors, wholesalers, agents, and trading companies** worldwide. Contact us today to explore collaboration opportunities and get a quote. Our **P40 Series hydraulic valve** is your reliable choice for various applications. Don't hesitate to contact us to discuss your specific requirements and benefit from our **factory direct pricing** and exceptional quality.
