P40-G12-G38 Hydraulic Valve | Wholesale Prices & Direct Factory Supply

Metoda sterowania:Ręczna

Szpula:3-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:24*21*13

Waga brutto:7.00 kg

Dostępność: W magazynie

1023 Osoby oglądają ten produkt

P40-G12-G38 Hydraulic Valve | Wholesale Prices & Direct Factory Supply

P40-G12-G38 Hydraulic Valve | Wholesale Prices & Direct Factory Supply

P40-G12-G38 Hydraulic Valve | Wholesale Prices & Direct Factory Supply drawing image

The P40-G12-G38 hydraulic valve is a 3-section, monoblock valve designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. This manual valve offers reliable control and high flow rates, making it ideal for telehandlers, forklifts, excavators, loaders, and more. Available at wholesale prices with direct factory supply.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-G38 is a high-performance hydraulic valve from the P40 series, known for its durability and reliability. Featuring a 3-section, monoblock design, this valve offers exceptional control over hydraulic systems in various applications. With a maximum pressure rating of 250 bar (3600 psi) and a rated flow of 40 L/min (10.5 US gpm), this valve ensures smooth and efficient operation. Its robust construction allows for reliable performance across a wide temperature range (-40°C to +80°C/-40°F to +176°F). This versatile valve is compatible with various equipment, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, midi-excavators, skid steer loaders, and compact wheel loaders. Directly sourced from the manufacturer, this valve is available at competitive wholesale prices, making it an ideal choice for businesses seeking high-quality hydraulic components at affordable prices.
