P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

Metoda sterowania:Ręczna

Szpula:1-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:23*16*11

Waga brutto:3.00 kg

Dostępność: W magazynie

1184 Osoby oglądają ten produkt

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier drawing image

The Lkf Flow Valve P40-G12-1OT is a high-performance hydraulic directional valve designed for use in a wide range of applications, including construction equipment, material handling, industrial vehicles, and agriculture. This manual control monoblock valve features a rated flow of 40 L/min and a maximum pressure of 250 bar, making it suitable for demanding applications. It is also compatible with a variety of equipment, including telehandlers, forklifts, all-terrain cranes, and more.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The Lkf Flow Valve P40-G12-1OT is a reliable and durable hydraulic directional valve designed for heavy-duty applications. It features a robust monoblock construction and a single spool, providing a compact and efficient design. The valve is equipped with a manual control system for easy operation and offers a rated flow of 40 L/min (10.5 US gpm) with a maximum pressure of 250 bar (3600 psi). It is suitable for operating viscosities ranging from 15 to 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve is specifically designed for use in construction equipment, material handling, industrial vehicles, and agriculture. It is compatible with a wide range of applications and equipment models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. This versatile and reliable hydraulic valve offers superior performance and durability, making it an ideal choice for a wide range of demanding applications.
