P120-G1 Monoblock Directional Valve | Precision Hydraulics

Metoda sterowania:Ręczna

Szpula:1-sekcyjny

Przepływ znamionowy:120 l/min (31.7 US gpm)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1

Port wylotowy:G1

Rozmiar portu:G1

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P120 Zawór sterujący jednoczęściowy

Rozmiar opakowania:19*35*16

Waga brutto:13.60 kg

Dostępność: W magazynie

1184 Osoby oglądają ten produkt

P120-G1 Monoblock Directional Valve | Precision Hydraulics

P120-G1 Monoblock Directional Valve | Precision Hydraulics

P120-G1 Monoblock Directional Valve | Precision Hydraulics drawing image

The P120-G1 Monoblock Directional Valve is a compact and robust hydraulic cylinder control unit designed for use in a wide range of applications including material handling, construction, and agriculture. It features a 120 L/min flow rate, 250 bar pressure rating, and a manual control method. This unit is perfect for applications requiring precise and reliable hydraulic control.

Seria P120 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny
Przepływ znamionowy 120 l/min (31.7 US gpm)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Port wylotowy G1, SAE 16, 1 NPT, M36×2
Rozmiar portu G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje
Typ konstrukcji Zawór blokowy
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)

The P120-G1 Monoblock Directional Valve is a high-performance hydraulic cylinder control unit that offers exceptional reliability and durability. Designed for use in demanding environments, it features a robust monoblock valve construction and a 120 L/min flow rate, making it ideal for a wide range of applications. Its 250 bar pressure rating ensures it can handle heavy loads and demanding operating conditions. The manual control method provides precise and easy operation, while its compact design allows for easy integration into various systems. This unit is particularly well-suited for use in telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. Its wide operating temperature range (-40°C to +80°C) ensures it can perform reliably in a variety of climates.
