OEM/ODM Customization for SD8 Manual 4 Spool Sectional Directional Valve

Metoda sterowania:Ręczna

Szpula:4-sekcyjny

Przepływ znamionowy:90 l/min (23,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G1/2

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór kierunkowy sekcyjny

Seria produktów:Seria SD8 Zawór kierunkowy sekcyjny

Rozmiar opakowania:32*36*16

Waga brutto:18.00 kg

Dostępność: W magazynie

87 Osoby oglądają ten produkt

OEM/ODM Customization for SD8 Manual 4 Spool Sectional Directional Valve

OEM/ODM Customization for SD8 Manual 4 Spool Sectional Directional Valve

OEM/ODM Customization for SD8 Manual 4 Spool Sectional Directional Valve drawing image

A high-performance SD8 series 4-spool sectional manual directional valve designed for precision control in mobile and industrial hydraulic systems, offering a rated flow of 80 L/min and operating pressure up to 315 bar.

Seria SD8 Zawór kierunkowy sekcyjny Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny, 8-sekcyjny, 9-sekcyjny, 10-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji, 8 Sekcji, 9 Sekcji, 10 Sekcji
Zakres lepkości roboczej 12 - 400 mm²/s (12 cSt do 400 cSt)
Przepływ znamionowy 90 l/min (23,8 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, SAE 10
Port wylotowy G1/2, G3/4, SAE 10, 3/4 NPT
Rozmiar portu G1/2, SAE 10

Our SD8 series manual 4-spool sectional directional valve is engineered for heavy-duty applications including agriculture, construction, and material handling. As a leading manufacturer, we provide comprehensive OEM, ODM, and custom branding services to meet specific technical requirements. This valve features a robust sectional design with a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure capability of 315 bar. It is compatible with forklifts, mini-excavators, and tractors. We offer competitive factory wholesale pricing and are actively seeking global distributors, wholesalers, agents, and traders for long-term collaboration. Our factory ensures stable supply and high manufacturing standards for all customized and wholesale orders tailored to your brand's market needs.
