NSH-10 Gear Pump: Factory Direct Supply from the Manufacturer

Pojemność skokowa:10 cm³/obr

Ciśnienie znamionowe:16 MPa (2320 psi)

Maksymalne ciśnienie:20 MPa (2900 psi)

Maksymalna prędkość:3000 obr./min

Kierunek obrotu:R: Prawo (zgodnie z ruchem wskazówek zegara)

Marka:BXHS

Typ produktu:Pompa hydrauliczna zębata

Seria produktów:Seria NSH Pompa hydrauliczna zębata

Rozmiar opakowania:20*15*13

Waga brutto:2.60 kg

Dostępność: W magazynie

1365 Osoby oglądają ten produkt

NSH-10 Gear Pump: Factory Direct Supply from the Manufacturer

NSH-10 Gear Pump: Factory Direct Supply from the Manufacturer

NSH-10 Gear Pump: Factory Direct Supply from the Manufacturer drawing image

NSH-10 Gear Pump is a high-quality hydraulic pump designed for various applications. With its 100 cc/rev displacement, 18 MPa rated pressure, and 2000 r/min rated speed, it offers exceptional performance and durability. As a leading manufacturer, we provide manufacturing, OEM, ODM, and customization services. Our commitment to quality and customer satisfaction makes us the ideal partner for your hydraulic pump needs.

Seria NSH Pompa hydrauliczna zębata Parametry
Pojemność skokowa 10 cm³/obr, 32 cm³/obr, 40 cm³/obr, 50 cm³/obr, 100 cm³/obr
Ciśnienie znamionowe 18 MPa (2610 psi)
Maksymalne ciśnienie 20 MPa (2900 psi)
Prędkość znamionowa 2000 obr./min
Maksymalna prędkość 4200 obr./min
Kierunek obrotu L: Lewo (przeciwnie do ruchu wskazówek zegara)
Materiał Aluminium
Struktura Zewnętrzna pompa zębata
Wersja kołnierza Flange kwadratowy B
Typ wału Nacięcie ewolwentowe X

The NSH-10 Gear Pump is engineered for optimal performance in demanding applications. Its robust construction, using high-quality aluminium, ensures durability and longevity. The square flange and involute spline shaft type provide secure and efficient connections. This pump is suitable for both left and right rotations, offering versatility in various equipment. Furthermore, its wide range of displacement options (10 cc/rev, 100 cc/rev, 40 cc/rev, 50 cc/rev) makes it adaptable to diverse flow requirements. As the manufacturer, we offer direct factory supply and wholesale prices, ensuring cost-effectiveness and prompt delivery. Our commitment to excellence extends to providing personalized customization services tailored to your specific requirements. Whether you require private labelling, OEM, or ODM services, we have the expertise and resources to meet your needs.
