Monoblock Directional Valve - Q45 Series | Wholesale & OEM

Metoda sterowania:Ręczna

Szpula:1-sekcyjny

Przepływ znamionowy:45 l/min (11,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria Q45 Zawór sterujący jednoczęściowy

Rozmiar opakowania:13*22*12

Waga brutto:4.00 kg

Dostępność: W magazynie

1121 Osoby oglądają ten produkt

Monoblock Directional Valve - Q45 Series | Wholesale & OEM

Monoblock Directional Valve - Q45 Series | Wholesale & OEM

Monoblock Directional Valve - Q45 Series | Wholesale & OEM drawing image

The Q45 Series Hydraulic Solenoid Valve Distributor Monoblock Directional Valve is a high-performance, reliable valve designed for use in a variety of mobile and industrial applications. It offers a rated flow of 45 L/min (11.8 US gpm) and a maximum pressure of 315 bar (4600 psi). This valve is available for wholesale and OEM orders.

Seria Q45 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Dźwignia sterownicza, Elektromagnetyczne i ręczne, Ręczny i elektromagnes dwukierunkowy (push-pull), Elektromagnes dwukierunkowy (push-pull)
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -20°C do +80°C (-4°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 45 l/min (11,8 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2
Port wylotowy G1/2
Rozmiar portu G1/2

This Q45 Series Hydraulic Solenoid Valve Distributor Monoblock Directional Valve is a versatile and reliable component for hydraulic systems. It features a compact monoblock design, providing a robust and efficient solution for various applications. The valve offers a rated flow of 45 L/min (11.8 US gpm) and can withstand a maximum pressure of 315 bar (4600 psi), making it suitable for demanding environments. It is designed for use in a variety of mobile and industrial applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. Some of its specific applications include telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The valve is available for wholesale and OEM orders. This valve is built for reliability, durability, and performance, ensuring smooth and efficient operation in your hydraulic systems.
