Monoblock Directional Valve Private Label & OEM Services | P80 Series

Metoda sterowania:Ręczna

Szpula:1-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*15*11

Waga brutto:5.00 kg

Dostępność: W magazynie

1143 Osoby oglądają ten produkt

Monoblock Directional Valve Private Label & OEM Services | P80 Series

Monoblock Directional Valve Private Label & OEM Services | P80 Series

Monoblock Directional Valve Private Label & OEM Services | P80 Series drawing image

The P80 Series Electrical Distributor Monoblock Directional Valve is a robust and reliable hydraulic component designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. It offers manual control, 1 section, and a rated flow of 80 L/min. We provide OEM and private label services to meet your specific needs.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Electrical Distributor Monoblock Directional Valve is a high-performance hydraulic valve that delivers exceptional reliability and durability. It features manual control for easy operation and is built with a robust monoblock structure. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for demanding applications in various industries. This valve is designed for use in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. We offer OEM and private label services, allowing you to customize the valve to your specific requirements. Whether you need a branded product or a custom-designed solution, our team can help you develop a valve that meets your exact needs. We are committed to providing high-quality products and exceptional customer service.
