Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM

Metoda sterowania:Pneumatyczna

Szpula:1-sekcyjny

Przepływ znamionowy:Przepływ 220 L/min

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1

Port wylotowy:G1

Rozmiar portu:G1

Marka:BXHS

Typ produktu:Zawór wywrotu

Seria produktów:Seria PC-1220 Zawór wywrotu

Rozmiar opakowania:40*18*16

Waga brutto:6.50 kg

Dostępność: W magazynie

1254 Osoby oglądają ten produkt

Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM

Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM

Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM drawing image

The Selonoid Hydraulic Valve Monoblock Directional Valve - PC-1220-250-1 Series is a high-performance valve designed for use in a variety of construction and industrial applications. It features a robust monoblock design and a rated flow of 220 L/min, making it suitable for demanding applications.

Seria PC-1220 Zawór wywrotu Parametry
Metoda sterowania Pneumatyczna
Szpula 1-sekcyjny
Przepływ znamionowy 220 l/min (58 galonów amerykańskich na min)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G1
Port wylotowy G1/2, G1
Rozmiar portu G1/4
Sekcja 1 Sekcja
Typ konstrukcji Zawór blokowy
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)

The Selonoid Hydraulic Valve Monoblock Directional Valve - PC-1220-250-1 Series is a reliable and durable valve designed for use in a variety of construction and industrial applications. It is a pneumatic control valve with a single section, monoblock structure, and a rated flow of 220 L/min (58 US gpm). The valve can withstand a maximum pressure of 250 bar (3600 psi) and operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). It features a single spool and is part of the PC-1220 Series. The valve can be used in a wide range of applications including material handling, construction and earth moving, agriculture, and industrial vehicles. This valve is suitable for use in various equipment such as telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. The valve is available for wholesale and OEM orders.
