Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*18*11

Waga brutto:8.00 kg

Dostępność: W magazynie

1158 Osoby oglądają ten produkt

Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design

Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design

Monoblock Directional Valve P80-G12-G38-QW: Compact and Robust Design drawing image

The P80-G12-G38-QW steering control valve is a compact and robust monoblock directional valve designed for demanding applications in material handling, construction, and agriculture. It features a manual control method, 2 sections, and a rated flow of 80 L/min. The valve is suitable for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, and excavators.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This P80 Series steering control valve is a high-performance, compact, and robust monoblock directional valve designed for demanding applications. With its manual control method and 2 sections, it provides precise and reliable control of hydraulic systems. The valve features a rated flow of 80 L/min and a maximum pressure of 250 bar. It is suitable for a wide range of applications, including material handling, construction, and agriculture. The valve's compact and robust design makes it ideal for use in tight spaces and demanding environments. Its high flow rate and pressure rating ensure reliable performance under heavy loads. The valve is compatible with various machines and equipment, such as telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, backhoe loaders, and skip loaders.
