Manufacturer of P40 Monoblock Valves: Wholesale & Customization Available

Metoda sterowania:Ręczna i joystick

Szpula:2-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40 Zawór sterujący jednoczęściowy

Rozmiar opakowania:23*18*13

Waga brutto:6.50 kg

Dostępność: W magazynie

919 Osoby oglądają ten produkt

Manufacturer of P40 Monoblock Valves: Wholesale & Customization Available

Manufacturer of P40 Monoblock Valves: Wholesale & Customization Available

Manufacturer of P40 Monoblock Valves: Wholesale & Customization Available drawing image

As a leading manufacturer of hydraulic products, we offer a wide range of P40 monoblock valves for various applications. Our valves are known for their durability, reliability, and efficiency, making them an ideal choice for demanding hydraulic systems.

Seria P40 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnes i joystick, Ręczna i joystick, Elektromagnetyczne i kablowe
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40 monoblock valves are available with manual and joystick control options, providing precise and responsive operation. With a rated flow of 40 L/min and a maximum pressure of 250 bar, these valves can handle a wide range of flow and pressure requirements. The valves are constructed from high-quality materials, ensuring long-lasting performance and durability. As a factory supplier, we offer competitive prices and flexible customization options to meet your specific requirements. Our valves are widely used in material handling, construction, agriculture, and industrial vehicles, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and harvesters.
