Manual 2 Spool Directional Valve P40-XNHJ | Industrial Hydraulic Solutions

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P40-XNHJ Zawór sterujący jednoczęściowy

Rozmiar opakowania:23*18*11

Waga brutto:5.00 kg

Dostępność: W magazynie

627 Osoby oglądają ten produkt

Manual 2 Spool Directional Valve P40-XNHJ | Industrial Hydraulic Solutions

Manual 2 Spool Directional Valve P40-XNHJ | Industrial Hydraulic Solutions

Manual 2 Spool Directional Valve P40-XNHJ | Industrial Hydraulic Solutions drawing image

The P40-XNHJ Series manual 2-spool directional valve offers a reliable and robust hydraulic control solution for various applications, including material handling, construction, and agriculture. It features a 40 L/min rated flow and a 250-bar maximum pressure, making it suitable for demanding industrial environments.

Seria P40-XNHJ Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Typ konstrukcji Zawór blokowy
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)

We are a global manufacturer of high-quality hydraulic products, offering manufacturing, OEM, private labeling, custom design, and wholesale services. Our P40-XNHJ Series manual 2-spool directional valve is a prime example of our commitment to excellence. This **monoblock valve** boasts a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi), making it ideal for diverse applications such as **material handling**, **construction and earth moving**, **agriculture**, and **industrial vehicles**. Specific applications include forklifts, telehandlers, skid steer loaders, tractors, mini-excavators, backhoes, balers, harvesters, and sprayers.

This robust and reliable **hydraulic valve** is designed for optimal performance in various operating conditions with an operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and an ambient temperature range of -40°C to +80°C (-40°F to +176°F). As a leading **hydraulic component** manufacturer, we offer flexible solutions including OEM services, private labeling, and custom design options to meet your specific needs. We also provide factory direct **wholesale valve** options for significant cost savings.

We are actively seeking distributors, wholesalers, agents, and trading companies to partner with us and expand our global reach. Contact us today to explore **OEM** opportunities, discuss your **custom valve** requirements, or learn more about our **wholesale** pricing and distribution partnerships. We are a factory supplier and offer **factory wholesale** pricing. We provide high-quality **industrial hydraulics** products. Contact us to discuss your needs!
