Large Scale Production of DCV60 Electro-hydraulic Sectional Valves

Metoda sterowania:Elektrohydrauliczna

Szpula:1-sekcyjny

Przepływ znamionowy:60 l/min (15,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór kierunkowy sekcyjny

Seria produktów:Seria DCV60 Zawór kierunkowy sekcyjny

Packagingsize:39*23*21

Grossweight:11.60 kg

Dostępność: W magazynie

93 Osoby oglądają ten produkt

Large Scale Production of DCV60 Electro-hydraulic Sectional Valves

Large Scale Production of DCV60 Electro-hydraulic Sectional Valves

Large Scale Production of DCV60 Electro-hydraulic Sectional Valves drawing image

The DCV60 series is a robust electro-hydraulic sectional valve designed for precise flow control in demanding mobile and industrial applications. With a 60 L/min rated flow and 350 bar pressure capacity, this valve offers reliable performance for construction, agriculture, and material handling machinery.

Seria DCV60 Zawór kierunkowy sekcyjny Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektromagnetyczne i ręczne, Elektromagnes i joystick, Ręczna i joystick, Silnik elektryczny
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny, 8-sekcyjny, 9-sekcyjny, 10-sekcyjny, 11-sekcyjny, 12-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji, 8 Sekcji, 9 Sekcji, 10 Sekcji, 11 Sekcji, 12 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 60 l/min (15,8 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi), 350 bar (5100 psi)
Port wlotowy G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

As a prominent large-scale manufacturer, we specialize in high-quality DCV60 Electro-hydraulic Sectional Valves engineered for heavy-duty performance in equipment like forklifts, tractors, mini-excavators, and skid steer loaders. We offer comprehensive factory-direct solutions including manufacturing, OEM, private labeling, and custom engineering to meet specific technical requirements. Our facility is equipped to handle large-scale wholesale orders with consistent quality assurance. We are actively seeking long-term partnerships with global distributors, wholesalers, trade agents, and industry-specific dealers. By working directly with us, you benefit from competitive factory-direct pricing, scalable production capacity, and reliable supply chain support. Whether you require standard modular configurations or tailored solutions for unique machinery builds, our engineering team is ready to support your business goals through professional manufacturing and personalized ODM/OEM services.
