JHP2080-2080 Hydraulic Gear Pump: Distributors & Wholesalers Wanted Globally

Pojemność skokowa:80 cm³/obr

Ciśnienie znamionowe:20 MPa (2900 psi)

Maksymalne ciśnienie:25 MPa (3625 psi)

Maksymalna prędkość:2500 obr./min

Kierunek obrotu:L: Lewo (przeciwnie do ruchu wskazówek zegara)

Marka:BXHS

Typ produktu:Pompa hydrauliczna zębata

Seria produktów:Seria Tandem JHP Pompa hydrauliczna zębata

Rozmiar opakowania:48*18*16

Waga brutto:34.00 kg

Dostępność: W magazynie

545 Osoby oglądają ten produkt

JHP2080-2080 Hydraulic Gear Pump: Distributors & Wholesalers Wanted Globally

JHP2080-2080 Hydraulic Gear Pump: Distributors & Wholesalers Wanted Globally

JHP2080-2080 Hydraulic Gear Pump: Distributors & Wholesalers Wanted Globally drawing image

JHP2080-2080, a high-pressure 80cc/rev internal gear hydraulic pump made of cast iron, ideal for various applications in construction, agriculture, and material handling. We offer OEM, private label, and custom solutions, and are actively seeking global distributors and wholesalers.

Seria Tandem JHP Pompa hydrauliczna zębata Parametry
Pojemność skokowa 10 cm³/obr, 32 cm³/obr, 40 cm³/obr, 63 cm³/obr, 80 cm³/obr, 100 cm³/obr, 125 cm³/obr, 140 cm³/obr, 160 cm³/obr, 90 cm³/obr, 16 cm³/obr
Ciśnienie znamionowe 16 MPa (2320 psi)
Maksymalne ciśnienie 20 MPa (2900 psi)
Prędkość znamionowa 2200 obr./min
Maksymalna prędkość 2500 obr./min
Kierunek obrotu L: Lewo (przeciwnie do ruchu wskazówek zegara), R: Prawo (zgodnie z ruchem wskazówek zegara)
Struktura Zewnętrzna pompa zębata
Materiał Żeliwo
Wersja kołnierza Flange kwadratowy B
Typ wału Nacięcie prostokątne H, P: Zwykły klucz

Introducing the JHP2080-2080 Hydraulic Gear Pump, a robust and reliable solution for diverse industrial applications. This high-pressure (16 MPa rated, 20 MPa max) 80cc/rev internal gear pump is manufactured from durable cast iron, ensuring longevity and performance. Its compact design and versatile flange (B-Square) and shaft options (Rectangle Spline or Plain Key) make it easily adaptable to a wide array of machinery. This pump is specifically designed for demanding environments, making it perfect for use in forklifts, skid steer loaders, compact wheel loaders, tractors and front-end loaders, mini and midi excavators, telehandlers, harvesters, balers, and sprayers.

**Key Features:**
* Displacement: 80 cc/rev
* Rated Pressure: 16 MPa (2320 psi)
* Max Pressure: 20 MPa (2900 psi)
* Rated Speed: 2000 r/min
* Max Speed: 2200 r/min
* Rotation: Right (clockwise) or Left (counter-clockwise)
* Structure: Internal Gear Pump
* Material: Cast Iron
* Flange Version: B-Square Flange
* Shaft Type: Rectangle Spline or Plain Key
* Series: JHP Tandem Series

**We are a leading hydraulic product manufacturer seeking to expand our global reach. We offer:**
* **Manufacturing:** High-quality production of our standard and custom hydraulic gear pumps.
* **OEM (Original Equipment Manufacturing):** Providing pumps tailored to your specifications.
* **Private Labeling:** Branding our pumps with your company logo and specifications.
* **Custom Design and Manufacturing:** Developing unique solutions to meet your specific needs.
* **Wholesale:** Competitive pricing and bulk order discounts.

**We are actively seeking:**
* Distributors
* Wholesalers
* Agents
* Trading Companies

Partner with us to tap into the growing global demand for high-quality hydraulic components. Contact us today to discuss collaboration opportunities and receive a quotation. As a factory direct manufacturer, we offer competitive pricing and reliable supply to our partners. Contact us for factory wholesale prices!
