Hydraulic Solenoid Valve | P80 Model | High-Precision & Reliable

Metoda sterowania:Elektromagnes

Szpula:3-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:200 bar (2900 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:33*28*13

Waga brutto:13.00 kg

Dostępność: W magazynie

1049 Osoby oglądają ten produkt

Hydraulic Solenoid Valve | P80 Model | High-Precision & Reliable

Hydraulic Solenoid Valve | P80 Model | High-Precision & Reliable

Hydraulic Solenoid Valve | P80 Model | High-Precision & Reliable drawing image

The P80 series two-way hydraulic control valve is a high-precision and reliable solenoid valve, designed for use in material handling, construction, agriculture, and industrial vehicle applications. It features a monoblock structure, 3 sections, and a rated flow of 80 L/min. The valve is built to withstand pressures up to 250 bar and operates in a wide viscosity range.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 series two-way hydraulic control valve is a high-performance solenoid valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. This valve offers a reliable and precise control of hydraulic fluid flow, making it ideal for a wide range of machines, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, excavators, skid steer loaders, and compact wheel loaders. The valve's monoblock structure ensures durability and a long service life. With a rated flow of 80 L/min and a maximum pressure rating of 250 bar, it provides efficient hydraulic operation. The valve's 3 sections and 3 spools allow for versatile control functions. Operating in a wide viscosity range, the P80 series valve delivers consistent performance across various working conditions.
