Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G1/2

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*18*11

Waga brutto:8.00 kg

Dostępność: W magazynie

1063 Osoby oglądają ten produkt

Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor

Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor

Hydraulic Directional Valve P80-G12-G34-OW | Manufacturer & Distributor drawing image

The P80-G12-G34-OW is a high-performance hydraulic directional valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. This manual control, 2-section monoblock valve offers a rated flow of 80 L/min and a maximum pressure of 250 bar, making it ideal for a wide range of mobile equipment.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G12-G34-OW is a reliable and durable hydraulic directional valve featuring a robust monoblock construction and a 2-spool design. It offers a rated flow of 80 L/min and a maximum pressure of 250 bar, ensuring efficient operation in demanding environments. The valve is suitable for various applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. The P80-G12-G34-OW is a manual control valve, allowing for precise and intuitive operation. With a wide operating viscosity range (15-75 mm²/s) and an ambient temperature range of -40°C to +80°C, this valve is designed to withstand diverse operating conditions. Its compact size and lightweight design make it easy to install and integrate into various hydraulic systems.
