Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Metoda sterowania:Ręczna

Szpula:4-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:SAE 10

Port wylotowy:SAE 10

Rozmiar portu:SAE 10

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*27*11

Waga brutto:13.40 kg

Dostępność: W magazynie

1053 Osoby oglądają ten produkt

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT

Hydraulic Control Valve, 4-Spool, Manual Operation - P80-U78-4OT drawing image

The Hydro Control P80-U78-4OT is a 4-spool, manually operated hydraulic control valve designed for heavy-duty applications in material handling, construction, and agriculture. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for use in a wide range of industrial vehicles including telehandlers, forklifts, cranes, and excavators.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The Hydro Control P80-U78-4OT is a robust and reliable hydraulic control valve designed for demanding applications. Its 4-spool, monoblock construction provides a compact and efficient design, while its manual operation allows for precise control of hydraulic functions. The valve is rated for a flow of 80 L/min and a maximum pressure of 250 bar, making it suitable for use in a wide range of industrial vehicles, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. The valve's operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) ensures optimal performance in various operating conditions. It can withstand ambient temperatures ranging from -40°C to +80°C (-40°F to +176°F), making it suitable for use in a variety of climates. The P80-U78-4OT is a reliable and durable solution for controlling hydraulic systems in a variety of demanding applications.
