HSDVG32 Control Valve Customization: OEM and ODM Services Available

Metoda sterowania:Proporcjonalna elektryczna i ręczna

Szpula:4-sekcyjny

Przepływ znamionowy:140 l/min (37 USGPM)

Maksymalne ciśnienie:350 bar (5100 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Proporcjonalny zawór sterujący

Seria produktów:Seria HSDVG32 Proporcjonalny zawór sterujący

Packagingsize:34*34*20

Grossweight:46.00 kg

Dostępność: W magazynie

1345 Osoby oglądają ten produkt

HSDVG32 Control Valve Customization: OEM and ODM Services Available

HSDVG32 Control Valve Customization: OEM and ODM Services Available

HSDVG32 Control Valve Customization: OEM and ODM Services Available drawing image

The HSDVG32 Electro Hydraulic Actuator is a high-performance control valve designed for a wide range of applications. It offers a robust design, high flow rate, and precise control, making it ideal for material handling, construction, agriculture, and industrial vehicles. We offer OEM and ODM services, allowing you to customize the actuator to meet your specific needs.

Seria HSDVG32 Proporcjonalny zawór sterujący Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczny i ręczny, Kabel, Proporcjonalna elektryczna, Elektromagnetyczne i ręczne, Proporcjonalna elektryczna i ręczna
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny, 8-sekcyjny, 9-sekcyjny, 10-sekcyjny, 11-sekcyjny, 12-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji, 8 Sekcji, 9 Sekcji, 10 Sekcji, 11 Sekcji, 12 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 140 l/min (37 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G3/4
Port wylotowy G3/4
Rozmiar portu G1/2, G3/4

The HSDVG32 Electro Hydraulic Actuator is a 4-section, sectional valve with a rated flow of 140 L/min and a maximum pressure of 315 bar. It features both electric proportional and manual control methods, allowing for precise and flexible operation. The valve is designed for demanding applications, with an operating viscosity range of 15 - 75 mm²/s and an ambient temperature range of -40°C to +80°C. The HSDVG32 series is compatible with various machines, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. We offer comprehensive OEM and ODM services, enabling you to customize the actuator to your specific requirements. Whether you need a standard model or a highly customized solution, we can tailor the product to meet your exact specifications. Our flexible manufacturing capabilities allow us to provide a wide range of options, including manufacturing, contract manufacturing, private labeling, and wholesale. We are actively seeking distributors, wholesalers, agents, and traders to expand our global reach and bring our high-quality products to a wider audience.
