HSBS06 Hydraulic Solenoid Valve with 3 Spool Configuration

Metoda sterowania:Elektromagnes

Szpula:3-sekcyjny

Przepływ znamionowy:30 l/min (7,9 US gpm)

Maksymalne ciśnienie:350 bar (5100 psi)

Port wlotowy:M18×1.5

Port wylotowy:M18×1.5

Rozmiar portu:M14×1,5

Marka:BXHS

Typ produktu:Zawór elektromagnetyczny

Seria produktów:Seria HSBS06 Zawór elektromagnetyczny

Rozmiar opakowania:34×31.5×32

Waga brutto:20.00 kg

Dostępność: W magazynie

103 Osoby oglądają ten produkt

HSBS06 Hydraulic Solenoid Valve with 3 Spool Configuration

HSBS06 Hydraulic Solenoid Valve with 3 Spool Configuration

HSBS06 Hydraulic Solenoid Valve with 3 Spool Configuration drawing image

The HSBS06 series is a high-performance 3-spool solenoid-operated hydraulic directional control valve designed for precise fluid management in mobile and industrial machinery. Featuring a rated flow of 30 L/min and capable of withstanding pressures up to 350 bar, this valve is engineered for durability and efficiency in demanding environments like construction and agriculture.

Seria HSBS06 Zawór elektromagnetyczny Parametry
Metoda sterowania Elektromagnes
Szpula 3-sekcyjny, 6-sekcyjny
Zakres temperatury otoczenia -20°C do +80°C (-4°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 3 Sekcje, 6 Sekcji
Zakres lepkości roboczej 12 - 400 mm²/s (12 cSt do 400 cSt)
Przepływ znamionowy 30 l/min (7,9 US gpm)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy M18×1.5
Port wylotowy M18×1.5
Rozmiar portu M14×1,5

As a leading manufacturer of large-scale hydraulic solutions, we present the HSBS06 Series 3-Spool Hydraulic Solenoid Valve for the global market. This robust valve is specifically designed for integration into tractors, front-end loaders, mini-excavators, and forklifts. With a maximum pressure rating of 5100 psi (350 bar) and M18x1.5 porting, it ensures reliable performance in heavy-duty applications such as material handling and earth moving. We offer comprehensive manufacturing services including OEM, private labeling, and custom design to meet your specific technical requirements. Our factory supply chain supports high-volume wholesale orders with a focus on quality and consistency. We are actively seeking long-term partnerships with international distributors, wholesalers, technical agents, and trading companies. Whether you need reliable components for wood splitters or advanced control for aerial platforms, our factory-direct wholesale model provides competitive advantages and professional technical support for your business growth.
