High Performance Q45 Solenoid and Manual Directional Control Valve 1 Spool

Metoda sterowania:Ręczny i elektromagnes dwukierunkowy (push-pull)

Szpula:1-sekcyjny

Przepływ znamionowy:45 l/min (11,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria Q45 Zawór sterujący jednoczęściowy

Rozmiar opakowania:28* 18*16

Waga brutto:8.00 kg

Dostępność: W magazynie

79 Osoby oglądają ten produkt

High Performance Q45 Solenoid and Manual Directional Control Valve 1 Spool

High Performance Q45 Solenoid and Manual Directional Control Valve 1 Spool

High Performance Q45 Solenoid and Manual Directional Control Valve 1 Spool drawing image

The High Performance Q45 Series is a versatile 1-spool directional control valve featuring both solenoid and manual operation. Designed for high-pressure applications up to 315 bar and a rated flow of 45 L/min, it provides reliable fluid power control for professional machinery across agriculture, construction, and material handling sectors.

Seria Q45 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Dźwignia sterownicza, Elektromagnetyczne i ręczne, Ręczny i elektromagnes dwukierunkowy (push-pull), Elektromagnes dwukierunkowy (push-pull)
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -20°C do +80°C (-4°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 45 l/min (11,8 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2
Port wylotowy G1/2
Rozmiar portu G1/2

As a leading large-scale manufacturer of hydraulic solutions, we offer the Q45 Series solenoid and manual directional control valve designed for demanding environments. This 1-spool valve supports a maximum pressure of 315 bar (4600 psi) and a flow rate of 45 L/min (11.8 US gpm), making it ideal for forklifts, tractors, mini-excavators, and aerial platforms. Our factory provides comprehensive services including OEM, private labeling (ODM), and custom manufacturing to meet specific system requirements. We are actively seeking global partners, including distributors, wholesalers, and trade agents to expand our international reach. With G1/2 porting and a robust monoblock design, this valve ensures precise operation for wood splitters and front-end loaders. We offer competitive factory wholesale pricing and stable supply chain support for bulk bulk purchases. Partner with a professional hydraulic manufacturer to access high-quality control valves engineered for industrial vehicles and earth-moving equipment.
