Global Distributors and Wholesalers Wanted for XPi-40L Hydraulic Piston Pump

Pojemność skokowa:40 cm³/obr

Ciśnienie znamionowe:38 MPa (5511 psi)

Maksymalne ciśnienie:42 MPa (6091 psi)

Maksymalna prędkość:1900 obr./min

Kierunek obrotu:L: Lewo (przeciwnie do ruchu wskazówek zegara)

Marka:BXHS

Typ produktu:Pompa hydrauliczna tłokowa

Seria produktów:Seria XPI Pompa hydrauliczna tłokowa

Rozmiar opakowania:34*17*17

Waga brutto:13.00 kg

Dostępność: W magazynie

161 Osoby oglądają ten produkt

Global Distributors and Wholesalers Wanted for XPi-40L Hydraulic Piston Pump

Global Distributors and Wholesalers Wanted for XPi-40L Hydraulic Piston Pump

Global Distributors and Wholesalers Wanted for XPi-40L Hydraulic Piston Pump drawing image

The XPi-40L Hydraulic Piston Pump delivers 40 cc/rev displacement with a rated pressure of 38 MPa (5511 psi) and max speed of 1900 r/min. Manufactured by a 25-year IATF 16949 certified factory, this left-rotation pump is ideal for mini-excavators, skid steers, and agricultural vehicles, offering reliable OEM/ODM solutions.

Seria XPI Pompa hydrauliczna tłokowa Parametry
Pojemność skokowa 32 cm³/obr, 40 cm³/obr, 45 cm³/obr, 50 cm³/obr, 63 cm³/obr, 80 cm³/obr, 25 cm³/obr, 108 cm³/obr.
Ciśnienie znamionowe 38 MPa (5511 psi)
Maksymalne ciśnienie 42 MPa (6091 psi)
Prędkość znamionowa 1600 obr./min
Maksymalna prędkość 1900 obr./min
Kierunek obrotu L: Lewo (przeciwnie do ruchu wskazówek zegara), R: Prawo (zgodnie z ruchem wskazówek zegara)
Materiał Żeliwo
Struktura Kołyska osiowa
Wersja kołnierza Otwory montażowe ISO-4
Typ wału Nacięcie prostokątne H

**1. High-Efficiency Hydraulic Piston Pump Specs**
- Delivers precise 40 cc/rev displacement with left-hand (counter-clockwise) rotation, optimized for compact hydraulic systems.
- Operates at a rated pressure of 38 MPa (5511 psi) and withstands max pressure up to 42 MPa (6091 psi), ensuring stable power output.

**2. Reliable XPi-40L Hydraulic Pump for Heavy Duty**
- Designed for rigorous applications including mini-excavators, skid steer loaders, and concrete boom pumps with a rated speed of 1600 r/min.
- Features advanced sealing technology and anti-rust treatment, guaranteeing longevity in harsh construction and earth-moving environments.

**3. Versatile 40cc Piston Pump Applications**
- Perfectly compatible with material handling equipment like forklifts, telehandlers, and wheel loaders, providing consistent flow control.
- Supports diverse industrial vehicles and agricultural tractors, serving as a direct replacement for international mainstream brands.

**4. Professional Manufacturer Quality Assurance**
- Backed by 25+ years of expertise and IATF 16949 certification, every unit undergoes 100% bench testing for pressure, flow, and leakage.
- Produced in 4 modern factories with 260+ machining centers, ensuring CE compliance and SGS-certified oil cleanliness standards.

**5. Factory Direct Sales & OEM/ODM Support**
- Offers comprehensive customization including private label laser marking, casting modifications, and tailored packaging for global distributors.
- With an annual capacity of 1,500,000 units, we provide wholesale China factory pricing and secure heavy-duty wooden crate shipping worldwide.
