Factory Wholesale QSF32 Load Sensitive Proportional Valve

Metoda sterowania:Proporcjonalny z czujnikiem obciążenia

Szpula:2-sekcyjny

Przepływ znamionowy:250 l/min (66 USGPM)

Maksymalne ciśnienie:230 bar (3300 psi)

Port wlotowy:M36×2

Port wylotowy:M36×2

Rozmiar portu:M18×1.5

Marka:BXHS

Typ produktu:Zawór do zamiatarki drogowej

Seria produktów:Seria QSF32 Zawór do zamiatarki drogowej

Packagingsize:27*27*20

Grossweight:35.00 kg

Dostępność: W magazynie

102 Osoby oglądają ten produkt

Factory Wholesale QSF32 Load Sensitive Proportional Valve

Factory Wholesale QSF32 Load Sensitive Proportional Valve

Factory Wholesale QSF32 Load Sensitive Proportional Valve drawing image

The QSF32 series represents a high-performance load-sensitive proportional valve designed for demanding industrial, agricultural, and construction applications. Engineered for precision flow control at 250 L/min and 230 bar, this 2-spool valve ensures efficiency and reliability for diverse heavy-duty equipment like loaders, excavators, and telehandlers.

Seria QSF32 Zawór do zamiatarki drogowej Parametry
Metoda sterowania Elektromagnes, Proporcjonalny z czujnikiem obciążenia
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje
Zakres lepkości roboczej 12 - 400 mm²/s (12 cSt do 400 cSt)
Przepływ znamionowy 250 l/min (66 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G1, SAE 16, 1 NPT, M36×2
Port wylotowy G1, SAE 16, 1 NPT, M36×2
Rozmiar portu G1, SAE 16, 1 NPT, M36×2

As a professional hydraulic manufacturer, we specialize in high-quality fluid power solutions for the global market. The QSF32 series load-sensitive proportional valve is built for durability, supporting advanced operational control in construction, material handling, and agricultural sectors. We offer comprehensive manufacturing services, including OEM, ODM, custom design, and large-scale wholesale supply. We are actively seeking long-term partnerships with global distributors, wholesalers, agents, and professional trade companies. By choosing our factory direct supply, you benefit from competitive pricing, rigorous quality control, and flexible customization tailored to your specific mechanical requirements. Whether you need branded hydraulic components or private label manufacturing, our technical team is prepared to support your project needs with efficient production lead times and reliable supply chain logistics. Partner with us to enhance your product portfolio with precision-engineered hydraulic solutions.
