Factory Direct Supply: SD11-PG2 Electro-hydraulic Monoblock Valves

Metoda sterowania:Elektrohydrauliczna

Szpula:4-sekcyjny

Przepływ znamionowy:70 l/min (18,5 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria SD11 Zawór sterujący jednoczęściowy

Rozmiar opakowania:29*30*20

Waga brutto:17.90 kg

Dostępność: W magazynie

540 Osoby oglądają ten produkt

Factory Direct Supply: SD11-PG2 Electro-hydraulic Monoblock Valves

Factory Direct Supply: SD11-PG2 Electro-hydraulic Monoblock Valves

Factory Direct Supply: SD11-PG2 Electro-hydraulic Monoblock Valves drawing image

Factory direct supply of high-quality SD11-PG2 electro-hydraulic monoblock valves. 4-section, 70 L/min rated flow, 315 bar max pressure. Ideal for material handling, construction, and industrial applications. Wholesale and OEM/ODM opportunities available.

Seria SD11 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Elektryczna, Pneumatyczne i ręczne
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny
Zakres temperatury otoczenia -40°C do +60°C (-40°F do +140°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 70 l/min (18,5 USGPM)
Maksymalne ciśnienie 305 bar (4400 psi), 315 bar (4600 psi)
Port wlotowy G3/4, SAE 12
Port wylotowy G3/4, SAE 12
Rozmiar portu G3/4, SAE 12

We are a leading manufacturer of high-performance electro-hydraulic monoblock valves, offering factory direct supply, OEM/ODM services, private labeling, customization, and wholesale options to global markets. Our SD11-PG2 valve is a robust 4-section unit boasting a 70 L/min rated flow and a maximum pressure of 315 bar (4600 psi). It's engineered for demanding applications in material handling, construction, and industrial vehicles, including forklifts, telehandlers, skid steer loaders, mini-excavators, tractors, harvesters, and balers.

This electro-hydraulic valve operates within a wide viscosity range (15-75 mm²/s) and ambient temperature range (-40°C to +60°C). Its durable monoblock construction ensures reliable performance in diverse environments. We are actively seeking distributors, wholesalers, agents, and trading companies to partner with us and expand our global reach.

**Key Features:**
* **Electro-hydraulic Control:** Precise and efficient operation.
* **Monoblock Design:** Robust and compact construction.
* **High Flow Rate (70 L/min):** Handles high-volume applications.
* **High Pressure Rating (315 bar):** Suitable for heavy-duty machinery.
* **Wide Operating Range:** Adaptable to various conditions.

**Business Opportunities:**
* **Factory Direct Supply:** Benefit from competitive pricing and shorter lead times.
* **OEM/ODM:** We can manufacture valves to your exact specifications.
* **Private Labeling:** Offer your own branded valves to your customers.
* **Customization:** Tailor the valve's features to your unique requirements.
* **Wholesale:** Take advantage of bulk purchasing discounts.

**Contact us today to explore partnership opportunities. We are a reputable manufacturer committed to providing high-quality products and exceptional customer service. Factory direct supply and factory wholesale are our strengths. Let's grow together!**
