Factory Direct Supply P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump

Pojemność skokowa:64,6 cm³/obr.

Ciśnienie znamionowe:16 MPa (2320 psi)

Maksymalne ciśnienie:17 MPa (2465 psi)

Maksymalna prędkość:2400 obr./min

Kierunek obrotu:Dwukierunkowy

Marka:BXHS

Typ produktu:Pompa hydrauliczna zębata

Seria produktów:Seria P21 Pompa hydrauliczna zębata

Rozmiar opakowania:45*25*18

Waga brutto:16.00 kg

Dostępność: W magazynie

187 Osoby oglądają ten produkt

Factory Direct Supply P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump

Factory Direct Supply P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump

Factory Direct Supply P21A646JEAL20-25 64.6 cc/rev Hydraulic Gear Pump drawing image

This Factory Direct Supply P21A646JEAL20-25 Hydraulic Gear Pump features a 64.6 cc/rev displacement, 16 MPa rated pressure, and bidirectional rotation for versatile application. Manufactured by a Professional Manufacturer with 25+ years of experience, it is ideal for wheel loaders, excavators, and agricultural machinery, ensuring reliable performance and OEM compatibility.

Seria P21 Pompa hydrauliczna zębata Parametry
Pojemność skokowa 64,6 cm³/obr.
Ciśnienie znamionowe 16 MPa (2320 psi)
Maksymalne ciśnienie 17 MPa (2465 psi)
Prędkość znamionowa 600 obr./min
Maksymalna prędkość 2400 obr./min
Kierunek obrotu Dwukierunkowy
Materiał Żeliwo
Struktura Zewnętrzna pompa zębata
Wersja kołnierza Flange owalny A, Flange kwadratowy B, Otwory montażowe ISO-4, Otwory montażowe UNI-3, Kołnierz SAE
Typ wału Nacięcie ewolwentowe X

**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers precise flow with 64.6 cc/rev displacement, operating at a rated speed of 2000 r/min and max speed of 2400 r/min.
- Handles demanding tasks with a rated pressure of 16 MPa (2320 psi) and max pressure of 17 MPa (2465 psi), ensuring stable power output.

**2. Versatile P21 Series Gear Pump Applications**
- Designed for broad compatibility with construction and earth-moving equipment, including wheel loaders, backhoe loaders, and skid steer loaders.
- Suitable for material handling and agricultural vehicles like forklifts, telehandlers, tractors, and dumpers, offering bidirectional rotation flexibility.

**3. Reliable 64.6cc Hydraulic Pump Quality Control**
- Produced in IATF 16949 certified facilities with 260+ machining centers; every unit undergoes 100% bench testing for pressure, flow, and sealing.
- Ensures cleanliness and durability through CMM inspection and SGS detection, backed by 25+ autonomous patents for consistent field performance.

**4. Customizable Construction Machinery Hydraulic Pump Solutions**
- Supported by 35+ senior engineers for full OEM/ODM services, including custom casting, appearance design, and laser logo branding.
- Offers Private Label options and direct replacement for major international brands, meeting specific technical requirements for global distributors.

**5. Factory Direct Sales & Global Logistics**
- Leverage Wholesale Direct Sales from a 68,000 sqm facility with an annual capacity of 1,500,000 units, ensuring short lead times.
- Products are secured with rust-proof treatment and heavy-duty wooden crate packaging, guaranteeing safe delivery for Exported Worldwide orders.
