Factory Direct: HSDVG32 Control Valves from the Manufacturer

Metoda sterowania:Proporcjonalna elektryczna i ręczna

Szpula:4-sekcyjny

Przepływ znamionowy:140 l/min (37 USGPM)

Maksymalne ciśnienie:350 bar (5100 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Proporcjonalny zawór sterujący

Seria produktów:Seria HSDVG32 Proporcjonalny zawór sterujący

Rozmiar opakowania:34*34*20

Waga brutto:46.00 kg

Dostępność: W magazynie

1031 Osoby oglądają ten produkt

Factory Direct: HSDVG32 Control Valves from the Manufacturer

Factory Direct: HSDVG32 Control Valves from the Manufacturer

Factory Direct: HSDVG32 Control Valves from the Manufacturer drawing image

HSDVG32 series hydraulic pressure regulator valves, manufactured by our factory, are available in electric proportional and manual control options, offering high flow rates (140 L/min), pressure ratings (315 bar) and suitability for a wide range of applications across industries like material handling, construction, agriculture, and industrial vehicles.

Seria HSDVG32 Proporcjonalny zawór sterujący Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczny i ręczny, Kabel, Proporcjonalna elektryczna, Elektromagnetyczne i ręczne, Proporcjonalna elektryczna i ręczna
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny, 8-sekcyjny, 9-sekcyjny, 10-sekcyjny, 11-sekcyjny, 12-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji, 8 Sekcji, 9 Sekcji, 10 Sekcji, 11 Sekcji, 12 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 140 l/min (37 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G3/4
Port wylotowy G3/4
Rozmiar portu G1/2, G3/4

We are a hydraulic products manufacturer, offering global market access for our HSDVG32 series hydraulic pressure regulator valves. These valves are available in both electric proportional and manual control methods, featuring a 4 section design with a sectional valve structure. They offer high flow rates of up to 140 L/min, with a maximum pressure rating of 315 bar. Designed for various operating environments, they have an operating viscosity range of 15 - 75 mm²/s and can withstand ambient temperatures from -40°C to +80°C. The 4 spool design and HSDVG32 series make them ideal for a variety of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. Specific models include telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. We offer factory direct supply, wholesale options, OEM, and customization services, as well as seeking distributors, wholesalers, agents, and traders.
