DCV58 Directional Valve | Precision Engineering and Durability

Metoda sterowania:Elektromagnes

Szpula:2-sekcyjny

Przepływ znamionowy:60 l/min (15,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G3/4

Marka:BXHS

Typ produktu:Zawór kierunkowy sekcyjny

Seria produktów:Seria DCV58 Zawór kierunkowy sekcyjny

Rozmiar opakowania:22*28*11

Waga brutto:10.00 kg

Dostępność: W magazynie

988 Osoby oglądają ten produkt

DCV58 Directional Valve | Precision Engineering and Durability

DCV58 Directional Valve | Precision Engineering and Durability

DCV58 Directional Valve | Precision Engineering and Durability drawing image

The DCV58 Series 5 Spool Solenoid Hydraulic Valve is a high-performance, durable directional valve designed for demanding applications in construction, material handling, agriculture, and industrial vehicles. With its 60 L/min flow rate and 350 bar pressure rating, this valve is suitable for various equipment such as telehandlers, forklifts, cranes, excavators, and loaders.

Seria DCV58 Zawór kierunkowy sekcyjny Parametry
Metoda sterowania Elektromagnes, Elektromagnetyczne i ręczne
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny, 8-sekcyjny, 9-sekcyjny, 10-sekcyjny, 11-sekcyjny, 12-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji, 8 Sekcji, 9 Sekcji, 10 Sekcji, 11 Sekcji, 12 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy G1/2, M22×1.5, SAE 10, 1/2 NPT
Port wylotowy G1/2, M22×1.5, SAE 10, 1/2 NPT
Rozmiar portu G1/2, M22×1.5, SAE 10, 1/2 NPT

The DCV58 Series 5 Spool Solenoid Hydraulic Valve is a precision engineered and durable valve offering reliable operation in demanding environments. It features a 2 section, sectional valve design with a 60 L/min rated flow and a 350 bar maximum pressure rating. The valve is suitable for a wide range of operating temperatures, from -40°C to +80°C. The DCV58 valve is specifically designed for applications such as material handling, construction and earth moving, agriculture, and industrial vehicles, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, and backhoe loaders. The valve's robust construction ensures longevity and reliable performance, making it a valuable component for hydraulic systems in a variety of industries.
