DCV40Z Monoblock Valve | Direct from Manufacturer | Customizable

Metoda sterowania:Ręczna

Szpula:5-sekcyjny

Przepływ znamionowy:40 l/min (10,5 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G1/2

Port wylotowy:G1/2

Rozmiar portu:G1/2

Marka:BXHS

Typ produktu:Zawór Sterujący Podporami

Seria produktów:Seria DCV40Z Zawór Sterujący Podporami

Rozmiar opakowania:39*39*20

Waga brutto:12.00 kg

Dostępność: W magazynie

466 Osoby oglądają ten produkt

DCV40Z Monoblock Valve | Direct from Manufacturer | Customizable

DCV40Z Monoblock Valve | Direct from Manufacturer | Customizable

DCV40Z Monoblock Valve | Direct from Manufacturer | Customizable drawing image

The DCV40Z series electric hydraulic distributor is a high-performance monoblock valve designed for demanding applications in construction equipment, material handling, and industrial vehicles. With a 40 L/min flow rate and 350 bar pressure rating, it offers reliable control and durability for heavy-duty operations.

Seria DCV40Z Zawór Sterujący Podporami Parametry
Metoda sterowania Ręczna, Elektrohydrauliczna, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 40 l/min (10,5 USGPM)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Port wylotowy G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Rozmiar portu G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The DCV40Z electric hydraulic distributor is a 5-section monoblock valve featuring a manual control method. It is capable of handling flow rates up to 40 L/min and pressures up to 350 bar. This valve is designed for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. The DCV40Z is known for its durability, reliability, and customizable options. Manufactured with high-quality materials, it offers excellent performance in demanding environments. Available directly from the manufacturer, this valve provides a cost-effective solution for various hydraulic system requirements.
