DCV20DY-OT Electro-hydraulic 1 Spool Monoblock Directional Valve

Metoda sterowania:Elektrohydrauliczna

Szpula:1-sekcyjny

Przepływ znamionowy:20 l/min (5,2 galonów amerykańskich na min)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G3/8

Port wylotowy:G1/2

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria DCV20 Zawór sterujący jednoczęściowy

Rozmiar opakowania:32*18*20

Waga brutto:3.40 kg

Dostępność: W magazynie

71 Osoby oglądają ten produkt

DCV20DY-OT Electro-hydraulic 1 Spool Monoblock Directional Valve

DCV20DY-OT Electro-hydraulic 1 Spool Monoblock Directional Valve

DCV20DY-OT Electro-hydraulic 1 Spool Monoblock Directional Valve drawing image

The DCV20DY-OT is a high-performance 1-spool electro-hydraulic monoblock directional control valve designed for compact applications requiring precise fluid management. With a rated flow of 20 L/min and a maximum pressure capacity of 350 bar, it is ideal for modern agricultural, construction, and material handling equipment.

Seria DCV20 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Elektrohydrauliczna, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 20 l/min (5,2 galonów amerykańskich na min)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Port wylotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Rozmiar portu G3/8, M18×1.5, SAE 8, 3/8 NPT

As a leading manufacturer of premium hydraulic products, we provide the DCV20DY-OT Electro-hydraulic Monoblock Valve engineered for demanding industrial environments. This 1-spool valve offers a compact footprint and high efficiency for machinery such as forklifts, mini-excavators, and aerial platforms. Our factory specializes in large-scale manufacturing, offering flexible OEM, ODM, and private labeling services to meet your specific technical requirements. We provide reliable factory wholesale supply and customization options for port sizes and spool configurations. We are actively seeking global partners, including professional distributors, wholesalers, agents, and traders, to expand our international market presence. By sourcing directly from our facility, you benefit from competitive factory pricing, consistent quality control, and robust supply chain support. Whether you need bulk wholesale orders or customized branding for your local market, our manufacturing team is equipped to deliver high-pressure hydraulic solutions that satisfy industrial standards worldwide.
