DCV20 Manual Hydraulic Monoblock Valve with 2 Spool Configuration

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:20 l/min (5,2 galonów amerykańskich na min)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G3/8

Port wylotowy:G3/8

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria DCV20 Zawór sterujący jednoczęściowy

Rozmiar opakowania:14*21*11

Waga brutto:3.90 kg

Dostępność: W magazynie

119 Osoby oglądają ten produkt

DCV20 Manual Hydraulic Monoblock Valve with 2 Spool Configuration

DCV20 Manual Hydraulic Monoblock Valve with 2 Spool Configuration

DCV20 Manual Hydraulic Monoblock Valve with 2 Spool Configuration drawing image

The DCV20 is a high-performance 2-spool manual hydraulic monoblock valve designed for versatile flow control in compact machinery. Rated for 20 L/min and capable of handling pressures up to 350 bar, this robust G3/8 ported valve is engineered for durability and precision in material handling, agriculture, and construction applications.

Seria DCV20 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Elektrohydrauliczna, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 20 l/min (5,2 galonów amerykańskich na min)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Port wylotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Rozmiar portu G3/8, M18×1.5, SAE 8, 3/8 NPT

As a leading large-scale hydraulic manufacturer, we present the DCV20 Series 2-Spool Manual Hydraulic Monoblock Valve, engineered for precision and reliability in demanding environments. This compact valve features a rated flow of 20 L/min (5.2 US gpm) and supports maximum operating pressures of 350 bar (5100 psi), making it ideal for forklifts, mini-excavators, tractors, and wood splitters. Our factory provides comprehensive solutions including OEM, ODM, and custom manufacturing tailored to your specific technical requirements. We specialize in bulk production and wholesale supply, ensuring consistent quality for global markets. We are actively seeking long-term partnerships with distributors, wholesalers, regional agents, and international traders. By choosing our factory-direct supply, you benefit from competitive wholesale pricing, flexible customization options, and professional technical support. Our DCV20 series is widely used in material handling, industrial vehicles, and agricultural machinery, serving as a reliable alternative for various mobile hydraulic applications. Contact us today to explore distribution opportunities and high-volume procurement programs.
