DCV20 Manual 2 Spool Monoblock Valve Direct from Hydraulic Factory

Metoda sterowania:Ręczna

Szpula:2-sekcyjny

Przepływ znamionowy:20 l/min (5,2 galonów amerykańskich na min)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G3/8

Port wylotowy:G3/8

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria DCV20 Zawór sterujący jednoczęściowy

Rozmiar opakowania:14*21*11

Waga brutto:3.90 kg

Dostępność: W magazynie

106 Osoby oglądają ten produkt

DCV20 Manual 2 Spool Monoblock Valve Direct from Hydraulic Factory

DCV20 Manual 2 Spool Monoblock Valve Direct from Hydraulic Factory

DCV20 Manual 2 Spool Monoblock Valve Direct from Hydraulic Factory drawing image

The DCV20 Series is a high-performance 2-spool manual monoblock directional control valve designed for compact hydraulic systems. Featuring a rated flow of 20 L/min and capable of withstanding pressures up to 350 bar, this versatile valve is engineered for precision control in material handling, agriculture, and construction machinery.

Seria DCV20 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Elektrohydrauliczna, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 20 l/min (5,2 galonów amerykańskich na min)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Port wylotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Rozmiar portu G3/8, M18×1.5, SAE 8, 3/8 NPT

As a leading manufacturer of premium hydraulic solutions, we offer the DCV20 Series 2-Spool Manual Monoblock Valve directly from our factory. This robust valve is designed for demanding applications including forklifts, mini-excavators, tractors, and wood splitters. Technical specifications feature a rated flow of 20 L/min (5.2 US gpm) and a maximum pressure rating of 350 bar (5100 psi) with G3/8 port sizes, ensuring compatibility with standard mobile hydraulic systems.

We provide comprehensive manufacturing services including OEM, private labeling (ODM), and custom design to meet your specific technical requirements. Our facility is equipped for large-scale production, ensuring stable factory wholesale pricing and consistent quality. We are actively seeking global partners to expand our distribution network. We welcome inquiries from professional distributors, wholesalers, regional agents, and international traders looking for a reliable factory supply. Partner with us for competitive wholesale advantages and high-quality hydraulic components tailored for sweepers, aerial platforms, and earth-moving equipment.
