Customize P80-G34-5OT Directional Valve to Your Needs

Metoda sterowania:Ręczna

Szpula:5-sekcyjny

Przepływ znamionowy:80 l/min (21,2 USGPM)

Maksymalne ciśnienie:250 bar (3600 psi)

Port wlotowy:G3/4

Port wylotowy:G3/4

Rozmiar portu:G3/4

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria P80 Zawór sterujący jednoczęściowy

Rozmiar opakowania:26*30*11

Waga brutto:16.00 kg

Dostępność: W magazynie

1045 Osoby oglądają ten produkt

Customize P80-G34-5OT Directional Valve to Your Needs

Customize P80-G34-5OT Directional Valve to Your Needs

Customize P80-G34-5OT Directional Valve to Your Needs drawing image

This 5-section, 250 bar rated, 80 L/min directional valve, part of the P80 series, is a high-performance, customizable hydraulic control valve perfect for construction, material handling, and agricultural equipment. It's a monoblock valve designed for demanding applications, offering robust reliability and precise control.

Seria P80 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Pneumatyczna, Elektropneumatyczna, Elektrohydrauliczna, Elektromagnes, Hydrauliczna, Hydrauliczny i ręczny, Kabel, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny, 7-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji, 7 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 80 l/min (21,2 USGPM)
Maksymalne ciśnienie 315 bar (4600 psi)
Port wlotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Port wylotowy G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Rozmiar portu G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

Our 2 Spool Joystick Hydraulic Control Valve, customizable P80-G34-5OT, is a high-performance directional valve designed to meet your specific needs. It's a 5-section monoblock valve with a rated flow of 80 L/min and a maximum pressure of 250 bar, ideal for a wide range of applications. This manual control valve boasts a compact design and features 5 spools, ensuring smooth and precise control. Its operating viscosity range is 15-75 mm²/s, and it operates flawlessly in ambient temperatures ranging from -40°C to +80°C. Designed for demanding applications, this valve is perfect for construction and earth moving, material handling, agricultural equipment, and industrial vehicles. Its versatility extends to a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, face drill rigs, concrete boom pumps, pave rollers, rotary drilling, and crushers. Customize your valve to fit your specific needs and enhance your equipment's performance.
