Boxinhuasheng Hydraulic - LKF60 Valve Manufacturer: Quality and Reliability Guaranteed

Metoda sterowania:Ręczna

Szpula:1-sekcyjny

Przepływ znamionowy:60 l/min (15,8 USGPM)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:3/8 NPT

Port wylotowy:3/8 NPT

Rozmiar portu:3/8 NPT

Marka:BXHS

Typ produktu:Zawór regulacji przepływu

Seria produktów:Seria LKF60 Zawór regulacji przepływu

Rozmiar opakowania:19*15*11

Waga brutto:3.80 kg

Dostępność: W magazynie

930 Osoby oglądają ten produkt

Boxinhuasheng Hydraulic - LKF60 Valve Manufacturer:  Quality and Reliability Guaranteed

Boxinhuasheng Hydraulic - LKF60 Valve Manufacturer:  Quality and Reliability Guaranteed

Boxinhuasheng Hydraulic - LKF60 Valve Manufacturer:  Quality and Reliability Guaranteed drawing image

The LKF60 Valve is a high-performance hydraulic control valve designed for a wide range of industrial and mobile applications. Manufactured to the highest quality standards, this valve offers exceptional reliability and durability. It is ideal for use in material handling, construction, agriculture, and industrial vehicles.

Seria LKF60 Zawór regulacji przepływu Parametry
Metoda sterowania Ręczna, Hydrauliczna
Szpula 1-sekcyjny
Zakres temperatury otoczenia -20°C do +80°C (-4°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 60 l/min (15,8 USGPM)
Maksymalne ciśnienie 210 bar (3045 psi)
Port wlotowy G3/8, G3/4, G3/8, G1/2, G3/4, 1/2 NPT, 3/4 NPT
Port wylotowy G3/8, G1/2, G3/4, 1/2 NPT, 3/4 NPT
Rozmiar portu G3/8, G1/2, G3/4, 1/2 NPT, 3/4 NPT, G3/8, G3/4, 1/2 NPT, 3/4 NPT

The LKF60 Valve is a monoblock valve with a rated flow of 60 L/min (15.8 US gpm) and a maximum pressure of 210 bar (3045 psi). It has an operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and an ambient temperature range of -40°C to +80°C (-40°F to +176°F). The valve features a single spool and is available in a variety of configurations to meet specific application requirements. As a leading manufacturer and supplier of hydraulic products, we offer a comprehensive line of valves, pumps, cylinders, and other components. Our products are manufactured using state-of-the-art equipment and undergo rigorous testing to ensure the highest levels of quality and reliability. We are committed to providing our customers with exceptional service and support, and we are always available to discuss your specific application needs.
