BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design

Pojemność skokowa:110 cm³/obr

Ciśnienie znamionowe:20 MPa (2900 psi)

Maksymalne ciśnienie:25 MPa (3625 psi)

Maksymalna prędkość:2500 obr./min

Kierunek obrotu:Dwukierunkowy

Sprzedawca:BXHS

Typ produktu:Pompa hydrauliczna zębata

Seria produktu:Seria BF Pompa hydrauliczna zębata

Packagingsize:34*20*17

Grossweight:24.90 kg

Dostępność: Na stanie

346 Osoby oglądają ten produkt

BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design

BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design

BF110M Hydraulic Gear Pump: Robust 20 MPa (2900 psi) Design drawing image

Discover the BF110M Hydraulic Gear Pump, engineered for robust performance in demanding applications. With a 110 cc/rev displacement and a rated pressure of 20 MPa, this cast iron pump offers reliable, bidirectional operation. It is suitable for a range of industries including material handling, construction, agriculture, and industrial vehicles, providing a dependable solution for diverse hydraulic system needs.

Seria BF Pompa hydrauliczna zębata Parametry
Pojemność skokowa 63 cm³/obr, 80 cm³/obr, 110 cm³/obr, 43 cm³/obr
Ciśnienie znamionowe 20 MPa (2900 psi), 25 MPa (3625 psi)
Prędkość znamionowa 2000 obr./min
Struktura Zewnętrzna pompa zębata, Wewnętrzna pompa zębata
Materiał Żeliwo
Typ wału Nacięcie prostokątne H, P: Zwykły klucz
Wersja kołnierza Flange owalny A, Otwory montażowe UNI-3
Maksymalne ciśnienie 25 MPa (3625 psi)
Kierunek obrotu Dwukierunkowy
Maksymalna prędkość 2500 obr./min

As a dedicated manufacturer and factory supplier of hydraulic products, we present the BF110M Hydraulic Gear Pump, a robust solution for a wide array of global applications. This **high-pressure gear pump** features a 110 cc/rev displacement and a rated pressure of 20 MPa (2900 psi), designed for consistent performance even under challenging conditions. Constructed from durable **cast iron**, the BF110M pump offers reliable, **bidirectional** operation, making it versatile for various hydraulic systems.

Our **BF Series pump** is highly adaptable, available with **UNI-3 mounting holes** or **A-oval flanges** and **rectangle spline** or **plain key shaft types**, ensuring compatibility with diverse machinery. It is an ideal **industrial hydraulic pump** for sectors such as **material handling**, **construction and earth moving**, **agriculture**, and general **industrial vehicles**. Specific applications include **telehandlers**, **forklifts**, **midi-excavators**, **skid steer loaders**, **wheel loaders**, **backhoe loaders**, **tractors and front-end loaders**, **harvesters**, **aerial platforms**, and **dumpers**.

We offer flexible partnership opportunities including **OEM hydraulic** manufacturing, **ODM services**, **private label** options, and **custom gear pump** solutions tailored to your specific requirements. We specialize in **factory wholesale** and large-scale supply. We are actively seeking long-term collaborations with **distributors**, **wholesalers**, **agents**, and **traders** globally to expand the reach of our quality hydraulic products. Partner with us for reliable **factory direct supply** and expertise in hydraulic pump manufacturing.
