6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier

Metoda sterowania:Ręczna i joystick

Szpula:6-sekcyjny

Przepływ znamionowy:20 l/min (5,2 galonów amerykańskich na min)

Maksymalne ciśnienie:315 bar (4600 psi)

Port wlotowy:G3/8

Port wylotowy:G3/8

Rozmiar portu:G3/8

Marka:BXHS

Typ produktu:Zawór sterujący jednoczęściowy

Seria produktów:Seria DCV20 Zawór sterujący jednoczęściowy

Rozmiar opakowania:32*35*2

Waga brutto:9.00 kg

Dostępność: W magazynie

1618 Osoby oglądają ten produkt

6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier

6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier

6 Spool Monoblock Directional Valve | Manufacturer & Global Supplier drawing image

This 6-spool monoblock directional valve is designed for various applications in construction, material handling, agriculture, and industrial vehicles. It offers manual and joystick control options and features a rated flow of 20 L/min and a max pressure of 350 bar.

Seria DCV20 Zawór sterujący jednoczęściowy Parametry
Metoda sterowania Ręczna, Elektrohydrauliczna, Dźwignia sterownicza, Ręczna i joystick
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny, 4-sekcyjny, 5-sekcyjny, 6-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór blokowy
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje, 4 Sekcje, 5 Sekcji, 6 Sekcji
Zakres lepkości roboczej 15 - 75 mm²/s (15 cSt do 75 cSt)
Przepływ znamionowy 20 l/min (5,2 galonów amerykańskich na min)
Maksymalne ciśnienie 350 bar (5100 psi)
Port wlotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Port wylotowy G3/8, M18×1.5, SAE 8, 3/8 NPT
Rozmiar portu G3/8, M18×1.5, SAE 8, 3/8 NPT

The Tractor Hydraulic Valve 6 Spool Monoblock Directional Valve is a high-performance, reliable hydraulic control valve specifically designed for heavy-duty applications in various industries. It features a robust monoblock construction with 6 spools, providing precise control of hydraulic functions. The valve is compatible with a wide range of equipment, including telehandlers, forklifts, excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, and harvesters. This versatile valve offers both manual and joystick control options, allowing for flexible operation. The DCV20 series valve boasts a rated flow of 20 L/min (5.2 US gpm) and a maximum pressure rating of 350 bar (5100 psi), making it suitable for demanding applications. With an operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and an ambient temperature range of -40°C to +80°C (-40°F to +176°F), this valve ensures reliable operation in a wide range of environments.
