2 Spool Directional Control Valve QSF32 Series

Metoda sterowania:Proporcjonalny z czujnikiem obciążenia

Szpula:2-sekcyjny

Przepływ znamionowy:250 l/min (66 USGPM)

Maksymalne ciśnienie:230 bar (3300 psi)

Port wlotowy:M36×2

Port wylotowy:M36×2

Rozmiar portu:M18×1.5

Marka:BXHS

Typ produktu:Zawór do zamiatarki drogowej

Seria produktów:Seria QSF32 Zawór do zamiatarki drogowej

Packagingsize:27*27*20

Grossweight:35.00 kg

Dostępność: W magazynie

113 Osoby oglądają ten produkt

2 Spool Directional Control Valve QSF32 Series

2 Spool Directional Control Valve QSF32 Series

2 Spool Directional Control Valve QSF32 Series drawing image

The QSF32 Series is a high-performance 2-spool load-sensing proportional directional control valve designed for heavy-duty applications. It offers a rated flow of 250 L/min and a maximum pressure of 230 bar, providing precise control for construction, agricultural, and material handling equipment.

Seria QSF32 Zawór do zamiatarki drogowej Parametry
Metoda sterowania Elektromagnes, Proporcjonalny z czujnikiem obciążenia
Szpula 1-sekcyjny, 2-sekcyjny, 3-sekcyjny
Zakres temperatury otoczenia -40°C do +80°C (-40°F do +176°F)
Typ konstrukcji Zawór sekcyjny
Sekcja 1 Sekcja, 2 Sekcje, 3 Sekcje
Zakres lepkości roboczej 12 - 400 mm²/s (12 cSt do 400 cSt)
Przepływ znamionowy 250 l/min (66 USGPM)
Maksymalne ciśnienie 250 bar (3600 psi)
Port wlotowy G1, SAE 16, 1 NPT, M36×2
Port wylotowy G1, SAE 16, 1 NPT, M36×2
Rozmiar portu G1, SAE 16, 1 NPT, M36×2

As a professional hydraulic manufacturer, we specialize in the production of the QSF32 Series 2-spool load-sensing directional control valves. Engineered for efficiency and durability, this series is compatible with wheel loaders, excavators, tractors, and telehandlers, ensuring seamless operation in demanding environments. We offer comprehensive global manufacturing services, including OEM, ODM, and private labeling, tailored to your specific mechanical requirements. Whether you require customized flow configurations or bulk wholesale orders, our factory-direct supply chain guarantees reliable quality and competitive pricing. We are actively seeking long-term partnerships with international distributors, wholesalers, and professional trade companies to expand our reach in the global market. Contact us today for bespoke hydraulic solutions, factory wholesale inquiries, and flexible manufacturing collaborations.
