Czas realizacji produkcji 15-30 dni
Innowacja napędza rozwój. Technologia tworzy przyszłość.
553 Osoby oglądają ten produkt
The PT-1220 Series 1 Spool Directional Valve is a high-performance, pneumatic valve designed for demanding industrial applications, such as material handling, construction, and agriculture. It features a compact sectional design, high flow capacity (200 L/min), and robust construction for reliable operation in harsh environments.
| Seria PT-1220 Zawór wywrotu Parametry | |
|---|---|
| Metoda sterowania | Pneumatyczna |
| Szpula | 1-sekcyjny |
| Zakres temperatury otoczenia | -40°C do +80°C (-40°F do +176°F) |
| Typ konstrukcji | Zawór blokowy |
| Sekcja | 1 Sekcja |
| Zakres lepkości roboczej | 12 - 400 mm²/s (12 cSt do 400 cSt) |
| Przepływ znamionowy | 220 l/min (58 galonów amerykańskich na min) |
| Maksymalne ciśnienie | 250 bar (3600 psi) |
| Port wlotowy | G1 |
| Port wylotowy | G1 |
| Rozmiar portu | G1 |
This 1 Spool Directional Valve from the PT-1220 Series is a high-flow, pneumatic valve designed for demanding industrial applications, including material handling, construction, and agriculture. With a rated flow of 200 L/min and a maximum pressure rating of 315 bar, this valve is suitable for controlling heavy-duty hydraulic systems. Its sectional design allows for easy customization and maintenance, while its robust construction ensures reliable performance in harsh environments. The valve's operating viscosity range is 12 - 400 mm²/s, and it can withstand ambient temperatures from -40°C to +80°C. This makes it suitable for a wide range of applications across different climates. Specifically, the PT-1220 Series valve is ideal for use in telehandlers, forklifts, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers, tractors, and front-end loaders.
